Grid Interface Options

Square Edge 15/16" Square
Edge 9/16"
Product
Selector
| |
| | Per Carton | | | Product Number |
Panel Size | Pieces |
Feet |
Weight |
| 5/8"
Thick | STN-110 |
24" x 24" | 24 |
96 | 24 |
| |
STN-111 |
24"
x 48" | 12 | 96 | 24 |
| | |
|
|
|
|
| 3/4" Thick |
STN-1120 |
24" x 24" | 32 |
128 | 34 | | | STN-1121 | 24"
x 48" | 16 | 128 |
34 |
| |
|
|
|
|
|
| 1" Thick |
STN-1140 |
24" x 24" | 24 |
96 | 34 |
| |
STN-1141 |
24"
x 48" | 12 | 96 | 34 |
| | STN-1142 |
48" x 48" | 12 |
192 | 67 | | | STN-1146 | 24" x 96" | 12 |
192 |
67 |
| | STN-1143 |
48" x 96" | 6 |
192 | 67 | | | STN-1144 | 24" x 60" | 12 |
120 |
42 |
| | STN-1147 |
48" x 60" | 6 |
120 | 42 | | | STN-1148 | 30" x 30" | 12 |
75 |
27 |
| | STN-1145 |
20" x 60" | 12 |
100 | 35 | | | STN-1149 | 30" x 60" | 12 |
150 |
52 |
| | |
|
|
|
|
| 1 1/2" Thick |
STN-1160 |
24"
x 24" | 16 | 64 | 34 |
| | STN-1161 |
24" x 48" | 8 |
64 | 34 |
| |
STN-1162 |
48"
x 48" | 8 | 128 | 67 |
| | STN-1166 |
24" x 96" | 8 |
128 | 67 | | | STN-1163 | 48" x 96" | 4 |
128 |
67 |
| | STN-1164 |
24" x 60" | 8 |
80 | 42 |
| |
STN-1167 |
48"
x 60" | 4 | 80 | 42 |
| | STN-1168 |
30" x 30" | 8 |
50 | 27 |
| |
STN-1165 |
20"
x 60" | 8 | 67 | 35 |
| | STN-1169 |
30" x 60" | 8 |
100 | 52 |
Physical Data
| | |
| | |
| Substrate | Medium density Fiberglass | | Nominal Sizes |
5/8" - 2'x2', 2'x4' |
| |
3/4" - 2'x2', 2'x4' |
| | 1"
- 2'x2', 2'x4', 4'x4', 2'x8', 4'x8', 2'x5', 4'x5',
30"x30", 20"x60", 30"x60" |
| |
1 1/2" - 2'x2', 2'x4', 4'x4',
2'x8', 4'x8', 2'x5', 4'x5', 30"x30", 20"x60",
30"x60" | | | Metric and Custom Sizes Available for all thicknesses. |
| Edge Detail | Square | | Fire Performance |
ASTM E 84 Class A |
| Surface Finish | Nubby - White, |
| |
Canyon Elite Vinyl (3mil) - White |
| Light Reflectance | LR-1 per ASTM E 1477 | | |
White Nubby (.85) White Canyon Elite (.84) |
| Thermal Resistance | 5/8" R=2.7 3/4" R=3.4
1" R=4.3 1 1/2" R=6.5 |
| Sound
Transmission | 5/8"
3/4" 1"
1 1/2" | | NRC |
.80-.90
.85-.95 .90-1.00 .95-1.05 |
|
CAC(with foil backing) | 20-24
20-24 20-24
25-29 | | AC |
180
190 190
210 | | Weight |
No foil 5/8"=.20 lbs/sf
3/4"=.25 lbs/sf 1"=.34 lbs/sf 1 1/2"=.50
lbs/sf | | | Foil 5/8"=.25 lbs/sf 3/4"=.30
lbs/sf 1"=.39 lbs/sf 1 1/2"=.55 lbs/sf |
| Backloading | 0.3 lbs. per square foot maximum on 24"x 24" and 24"x 48"
panels only | | Moisture
Resistance | RH 95°™ | | |
will not exhibit visible
warp or sag under conditions not exceeding 95% relative humidity at 104° F(32° C) per
ASTM C367 | | Suspension Systems |
15/16" and 9/16" T-bar
Suspension Grid | | Use |
Suitable for use as an interior ceiling in conditioned
space. | | | May be installed during wet phases of construction. |
| Warranty |
25 Year Limited Warranty |
| ASTM E 1264 Classification |
Type XII, Form 1,2 Patterns C,
E, I |
|
